1. Made of biocompatible silicone material
2. Color coding for size identification
3. Plastic valve only
4. Sterilized by EO
5. For single use only
6. Available with different types
| 2-way Pediatric | ||||
| Size (Fr/Ch) | Balloon (mL) | Color Code | Length (mm) | Cat. No. (Plastic Valve) |
| 6 | 1.5 | Light red | 310 | F01B040601 |
| 8 | 3-5 | Black | 310 | F01B040803 |
| 10 | 3-5 | Grey | 310 | F01B041003 |
| 2-way Standard | ||||
| Size (Fr/Ch) | Balloon (mL) | Color Code | Length (mm) | Cat. No. (Plastic Valve) |
| 12 | 10 | White | 400 | F01B011207 |
| 14 | 10 | Green | 400 | F01B011407 |
| 16 | 10 | Orange | 400 | F01B011607 |
| 18 | 30 | Red | 400 | F01B011810 |
| 20 | 30 | Yellow | 400 | F01B012010 |
| 22 | 30 | Violet | 400 | F01B012210 |
| 24 | 30 | Blue | 400 | F01B012410 |
| 26 | 30 | Pink | 400 | F01B012610 |
| 2-way Female | ||||
| Size (Fr/Ch) | Balloon (mL) | Color Code | Length (mm) | Cat. No. (Plastic Valve) |
| 12 | 10 | White | 260 | F01B031207 |
| 14 | 10 | Green | 260 | F01B031407 |
| 16 | 10 | Orange | 260 | F01B031607 |
| 18 | 30 | Red | 260 | F01B031810 |
| 20 | 30 | Yellow | 260 | F01B032010 |
| 22 | 30 | Violet | 260 | F01B032210 |
| 3-way Standard | ||||
| Size (Fr/Ch) | Balloon (mL) | Color Code | Length (mm) | Cat. No. (Plastic Valve) |
| 16 | 30 | Orange | 400 | F01B061610 |
| 18 | 30 | Red | 400 | F01B061810 |
| 20 | 30 | Yellow | 400 | F01B062010 |
| 22 | 30 | Violet | 400 | F01B062210 |
| 24 | 30 | Blue | 400 | F01B062410 |
| 26 | 30 | Pink | 400 | F01B062610 |
| * Available with 3mL, 5mL, 5-10mL, 5-15mL, 15mL, 20mL, 30-50mL balloon. Please check the product brochure for more specifications. | ||||
|
|
|
|
|
|
|
|
|
|
|
|
